India’s large format print producers evaluating UV roll-to-roll printing will find a broad choice in the EFI VUTEk range — multiple sub-families covering throughput from 256 to 751 m²/hr.
The right machine depends on your production volume, print width requirement, and application mix. A shop running high-volume OOH banners needs a different model from one specialising in vehicle wraps or retail POP. Getting that decision right from the outset determines how quickly the investment pays back.
This guide covers the complete EFI VUTEk roll-to-roll printers lineup — with a full specification table, a model selector framework, and a deep-dive into the Q3r and Q5r for display graphics operations. All models are available through Arrow Digital India, your authorised partner for EFI VUTEk large format printers in India.
Roll-to-roll UV printing delivers the speed, substrate versatility, and outdoor durability that India’s display graphics sector demands from a production machine.
India’s outdoor advertising, retail POP, vehicle graphics, and event banner sectors continue to scale. Print producers competing in these verticals face two consistent pressures: faster turnaround expectations from clients and the need to work across a wider substrate range — from backlit films and mesh banners to vehicle wrap vinyl and coated polyester.
UV-curable ink addresses both. Unlike eco-solvent, UV ink cures instantly under LED lamps, enabling immediate post-print handling and higher throughput without a drying tunnel. It is also compatible with substrates that eco-solvent cannot reliably hold, including heat-sensitive films and non-porous specialty media. For OOH advertising printing India, where colour intensity and outdoor durability are non-negotiable, roll-to-roll UV has become the production standard for serious operations.
Arrow Digital India, authorised EFI VUTEk distributor, carries the complete active r-series. The range spans 3.2 m to 5.28 m print widths across four sub-families — X series, Q series, r+ series, and Pro series — each engineered for a specific production profile.
The EFI VUTEk r-series covers 3.2 m to 5.28 m print widths at up to 1,200 dpi across four model families with UV-LED curing throughout.
All models in the range share EFI VUTEk’s UV-LED curing platform, optional white ink, and up to 1,200 dpi resolution. They are organised into four sub-families by production priority:
Model | Series | Max Width | Max Speed | Resolution |
EFI VUTEk X5r | X Series | 5.28 m (208 in.) | 751 m²/hr(8,084 ft²/hr) | Up to 1,200 dpi |
EFI VUTEk X3r | X Series | 3.48 m (137 in.) | 610 m²/hr(6,565 ft²/hr) | Up to 1,200 dpi |
EFI VUTEk Q5r | Q Series | 5.2 m (205 in.) | 672 m²/hr(7,233 ft²/hr) | Up to 1,200 dpi |
EFI VUTEk Q3r | Q Series | 3.5 m (138 in.) | 558 m²/hr(6,006 ft²/hr) | Up to 1,200 dpi |
EFI VUTEk 5r+ | r+ Series | 5.2 m (205 in.) | 487 m²/hr(5,242 ft²/hr) | Up to 1,200 dpi |
EFI VUTEk 3r+ | r+ Series | 3.5 m (138 in.) | 406 m²/hr(4,370 ft²/hr) | Up to 1,200 dpi |
EFI Pro 33r | Pro Series | 3.2 m (126 in.) | 343 m²/hr(3,692 ft²/hr) | Up to 1,200 dpi |
EFI Pro 32r+ | Pro Series | 3.2 m (126 in.) | 256 m²/hr(2,756 ft²/hr) | Up to 847 dpi |
Three variables determine the right EFI VUTEk roll-to-roll model: required print width, target throughput, and primary application type.
Most production operations fall clearly into one row of the selector below. Where two models share a row, the distinction is typically width (5.2 m vs 3.5 m) or gamut priority — the X series prioritises throughput; the Q series prioritises extended colour depth.
If your priority is… | Recommended Model | Why |
Maximum throughput, widest format | X5r | Fastest model at 751 m²/hr (8,084 ft²/hr); 5.2 m width; designed for banner farms and wide OOH |
High speed + PRINT–COAT–CUT at 3.5 m | X3r | 610 m²/hr (6,565 ft²/hr) with inline workflow; also suited to truck side curtain production |
Vehicle graphics, fleet wraps, 3M warranty | Q5r | EFI’s designated fleet and vehicle graphics model; 3M SuperFlex Ink; 7-year 3M MCS Warranty |
Premium POP, OOH, extended gamut at 3.5 m | Q3r | 9-colour configuration; UltraDrop quality; PRINT–COAT–CUT inline |
Wide-width display + PRINT–COAT–CUT at mid-volume | 5r+ | 5.2 m with inline workflow at 487 m²/hr (5,242 ft²/hr); extended gamut; solid mid-volume wide display |
PRINT–COAT–CUT + truck side curtains at 3.5 m | 3r+ | 406 m²/hr (4,370 ft²/hr) with inline workflow; extended gamut; strong mid-range entry point |
Profitability + competitive advantage, growing PSP | Pro 33r | Pro series top model; 343 m²/hr (3,692 ft²/hr); up to 1,200 dpi; white or clear ink optional |
Entry into EFI VUTEk quality at lower capital commitment | Pro 32r+ | 256 m²/hr (2,756 ft²/hr); up to 847 dpi; 3.2 m; white or clear ink optional |
The EFI VUTEk Q3r and Q5r are the extended-gamut specialists in the lineup — built for print producers who need both high production throughput and premium output quality.
Both models support up to nine ink colours — CMYK plus optional light cyan, light magenta, light black, white, and clear — giving operations the colour depth needed for cosmetic-grade retail POP, premium backlit graphics, and multi-layer white ink applications. At 558 m²/hr (6,006 ft²/hr) (Q3r) and 672 m²/hr (7,233 ft²/hr) (Q5r), these are high-production machines, not quality-only devices.
UltraDrop is the multi-drop addressable print head system used across the Q series — the technology behind the precision output these models deliver at production speeds.
Multi-drop addressability
Each nozzle fires variable drop sizes in a single pass — larger drops in solid coverage areas and smaller drops in fine detail regions simultaneously — without slowing output speed. This is what separates the Q series quality floor from single-drop UV systems at comparable throughput.
Shadow and gradient reproduction
Variable drop placement produces smooth tonal transitions in shadow areas and gradients, eliminating the visible banding that lower-resolution UV printers show when running at high production speeds.
Text sharpness at production speed
At up to 1,200 dpi with 7pL UltraDrop™ precision, the Q series renders 3-point text legibly — a production requirement for retail POP, cosmetic displays, and any application where fine copy appears in the printed artwork.
White and clear ink channels
Optional white and clear ink on the Q3r and Q5r enable multi-layer printing — white base, then colour over-print, then optional clear coat — supporting backlit graphics on transparent substrates and premium surface finishes on display and retail work.
The EFI VUTEk Q5r is EFI’s designated fleet and vehicle graphics model within the VUTEk r-series, qualifying for the 7-year 3M MCS Warranty when printed with 3M SuperFlex Ink.
When printed with 3M SuperFlex Ink, the Q5r qualifies for the 3M MCS Warranty for EFI printers — the 7-year quality assurance for vehicle wrap durability. Other VUTEk models including the Q3r, 5r+, and 3r+ also qualify with the same ink system. At 5.2 m print width, the Q5r is the widest VUTEk option for fleet and vehicle graphics, enabling full-width vehicle side graphics in a single pass and eliminating joins on large vehicle and trailer applications.
Where the Q5r leads on width and vehicle graphics positioning, the Q3r’s strength is quality-per-square-metre at 3.5 m — the format most commonly required for retail display, hoarding art, and POP production in India.
Its 9-colour configuration and PRINT–COAT–CUT compatibility make the Q3r a natural production anchor for retail environments where display quality is the differentiator. For backlit display printing on transparent film, the optional white ink channel enables the under-print workflow that backlit applications require. See also EFI VUTEk Q5r and Q3r for a full model comparison.
The EFI VUTEk X5r and X3r are the throughput leaders in the r-series — built for operations where production speed determines profitability above all other variables.
The X5r reaches 751 m²/hr (8,084 ft²/hr) at 5.2 m print width (208 in.), making it the fastest roll-to-roll model in the active EFI VUTEk lineup. For banner farms, wide-format outdoor signage, and high-volume hoarding graphic production, the X5r reduces machine time per job to a level that fundamentally changes the economics of running display work at scale.
The X3r operates at 610 m²/hr at 3.48 m and adds PRINT–COAT–CUT inline workflow support — making it a dual-purpose model for operations that need throughput on banner work but also run truck side curtain and coated outdoor graphics production. Both X series models support optional white and clear ink for backlit and specialty media applications.
The key production distinction between the X and Q series: the Q series carries the extended gamut ink option (light cyan, light magenta, light black) for cosmetic-grade colour rendering and shadow depth. The X series does not. That is the deliberate trade-off — the right one for high-volume banner and signage production where turnaround speed is the competitive differentiator.
The EFI Pro 33r and Pro 32r+ bring EFI roll-to-roll LED print quality to a 3.2 m format — the entry point into the EFI Pro series for print operations scaling up from lower-resolution or eco-solvent systems.
The Pro 33r runs at 343 m²/hr (3,692 ft²/hr) with resolution up to 1,200 dpi and optional white or clear ink. EFI positions the Pro 33r explicitly around profitability and competitive advantage — the ability to produce EFI VUTEk quality output at a production volume and capital investment level that works for a growing print operation rather than a high-volume banner factory. For PSPs stepping up from entry-level UV or eco-solvent systems, the Pro 33r delivers EFI colour management and substrate flexibility without the floor space or capital commitment of the X or Q series.
The Pro 32r+ operates at 256 m²/hr (2,756 ft²/hr) at up to 847 dpi — the most accessible entry point into the EFI Pro series. Optional white or clear ink is available. It is the natural upgrade path for sign shops and display producers currently running eco-solvent who want to move to UV without a complete workflow overhaul. The 3.2 m format covers the majority of standard display and signage applications, and EFI Fiery workflow integration means the shift to UV production does not require retraining from scratch.
The EFI VUTEk 5r+ and 3r+ are built around the PRINT–COAT–CUT inline production workflow — print, apply a surface coating, and cut the media in a single pass without re-registering the substrate.
The 5r+ handles 5.2 m at 487 m²/hr and includes extended gamut ink capability, making it a wide-width production option for operations that need both inline finishing and the colour depth that lc/lm/lk channels provide. The 3r+ covers 3.5 m at 406 m²/hr with the same PRINT–COAT–CUT workflow and also carries official positioning for truck side curtain production — a high-volume application that requires both the print width and an inline coating step to achieve the surface durability that road use demands.
The PRINT–COAT–CUT workflow removes the separate lamination or coating step entirely. That means no re-registration of the media, no separate floor space for a standalone coater, and no additional handling time per job. The stronger case for the r+ series is extended gamut with inline finishing at a throughput tier below the X series — not exclusivity of the PRINT–COAT–CUT workflow itself.
Looking for the right EFI VUTEk roll-to-roll model for your operation? Arrow Digital India is the authorised distributor for the complete r-series — X5r/X3r, Q5r/Q3r, 5r+/3r+, Pro 33r/Pro 32r+. Request a demo or speak to our team to match the right machine to your production volume and application mix.
Eight active models are available through Arrow Digital India, the authorised EFI distributor: X5r, X3r, Q5r, Q3r, 5r+, 3r+, Pro 33r, and Pro 32r+. These span print widths from 3.2 m to 5.2 m and throughput speeds from 256 m²/hr to 751 m²/hr.
The X series (X5r, X3r) prioritises throughput — the X5r is the fastest model at 751 m²/hr (8,084 ft²/hr). The Q series (Q5r, Q3r) prioritises extended colour gamut, supporting up to nine ink colours including light cyan, light magenta, and light black for premium POP and display graphics output. The Q series carries extended gamut capability; the X series does not.
The EFI VUTEk Q5r is EFI’s designated fleet and vehicle graphics model within the VUTEk r-series. When printed with 3M SuperFlex Ink, the Q5r qualifies for the 7-year 3M MCS Warranty — the industry-standard quality assurance for vehicle wrap durability. Its 5.2 m width enables full-width vehicle side graphics in a single pass.
PRINT–COAT–CUT is an inline production workflow that prints, applies a surface coating, and cuts the media in a single pass without re-registering the substrate. It is supported on the X3r, Q3r, 5r+, and 3r+. The workflow eliminates the need for a separate coating station and reduces handling time per job.
UltraDrop is EFI’s multi-drop addressable print head system used on the Q series. It allows each nozzle to fire variable drop sizes in a single pass — producing smooth gradients, precise shadow detail, and legible 3-point text at 7pL precision and up to 1,200 dpi resolution.
Yes. White and clear are optional ink channels on the X, Q, and r+ series models. White ink enables backlit and window graphic production on transparent substrates; clear ink supports inline coating for outdoor durability and surface finish. On the Pro 33r and Pro 32r+, white or clear is available as a single optional channel — one or the other depending on configuration.
The EFI VUTEk X5r is the fastest model in the active lineup at up to 751 m²/hr (8,084 ft²/hr) at 5.2 m (208 in.) print width. It is designed for banner farms, wide-format outdoor signage, and high-volume display applications where throughput is the primary production constraint.
Arrow Digital India is the authorised EFI distributor for the complete EFI roll-to-roll lineup. To discuss which model fits your production requirements, request a demo or contact the Arrow Digital team.
