EFI™ Pro 30h
A hybrid LED entry-level production printer is strategically positioned to offer superior image quality, versatility, and productivity at a competitive price point;


Speed
Up to 2,477 ft²/hr


Colour
4 Color + White


Width
3.2 Meters


Resolution
UltraDrop™ Tech with native 7 pL , Resolution up to 1200 dpi


Capabilities
Up to 5 Layer Printing


Certifications
Greenguard Gold/Greenguard Certified
The Best Entry Level Production Printer
The EFI™ Pro 30h hybrid flatbed/roll-fed LED entry-level production printer brings a whole new meaning to the word “wide.”
It prints on a wide variety of substrates for a wide variety of applications, all with superior image quality and environmentally friendly benefits. The result is that the EFI Pro 30h broadens your capabilities, versatility and productivity – all at a very attractive price point.
A cost-effective, 3.2-meter hybrid printer that delivers the consistency, versatility and environmentally friendly benefits that have made EFI LED hybrid printers the clear choice in the marketplace –now available to the entry level market.
The 3.2-metre EFI Pro 30h printer is ideal for commercial printers, sign shops and in-plant printers looking to start, upgrade or add board and roll-to-roll print jobs to their wide format capabilities. This CMYK printer comes standard with two channels of white for those high-value prints. It features UltraDrop™ Technology 7pL printheads with greyscale printing up to 1200 dpi and a magnetic linear drive for better drop placement,
resulting in a greater colour gamut. EFI white ink leads the industry in brightness and opacity, and can be imaged like any other colour, in greyscale,
up to 1200 dpi, and using our multilayer printing with up to five layers in a single pass.
- Standard CMYK plus two white channels
- Dynamic curing Led UV lamps
- Grayscale printing up to 1200dpi
- Productivity up to 2477 ft2 ,or 60 BPH
- Optional Clear channel
- Print up to 5 layers in a single pass
- Dual roll printing
- Continuous Board printing
- Rigid and flexible media support
- Advanced media-platen vacuum system with 6 chambers having their own independent vacuum power controls
- Dual touchscreen graphical user interface in front and back of printer for ease of
operation in multiple applications - Optional EFI ProGraphics™ UV LED curing ink sets to choose from
- Embedded Fiery proServer Core digital front end
Media/handling
- Maximum printable width: 320cm
- Maximum media thickness: 5.08cm
- Size zone,user-selectable vacuum system
- Maximum media weight on table: 90.7kg
- Maximum roll weight: 200 kg
- Maximum roll diameter: 30.5 cm
Productivity
- Express mode maximum speed: 230 m2/hr
- White printing at one-half CMYK speeds
File Format
- All popular desktop files formats,including Adobe® PostScript® 3™ ,EPS,TIFF,PDF,and RGB/CMYK
Environmental Considerations
- Temperature: 20 °C–30 °C
- Humidity: 40%–80% (non-condensing)
- Weight: Approximately 3100 kg uncrated
- Electrical: 200-240VAC,single phase,50/60 Hz 32A
- Dimensions (W x D x H): 575 cm x 192 cm x 194 cm
EFI Prographics Series UV inks
- 5.0-litre containers
- Twelve-month shelf life
EFI Fiery Digital Front End
- Ships with an EFI Fiery proServer Core digital front end
