Media/Handling
- Prints up to 134 in (340 cm) wide
- Fabric weight from 30 to 450 gr/m2
- Entry: Configured with both a standard roll unwinder up to 16 in (400 mm) OD and heavy-duty unwinder for rolls up to 35 in (900 mm) OD
- Exit: Configured with either a heavy-duty rewinder for rolls up to 35 in (900 mm) OD or a revolving turret
- Dryer: One chamber industrial available in either gas or electric
Productivity*
| | 16 heads | 32 heads |
| Production Quality | 8,417 ft2 / 782 m2 | 16,835 ft2 / 1,564 m2 |
| POP Quality | 4,391 ft2 / 408 m2 | 8,783 ft2 / 816 m2 |
| High Quality | 2,195 ft2 / 204 m2 | 4,392 ft2 / 408 m2 |
*Speeds are up to the maximum productivity figures listed
Color Configurations
Formats
All popular desktop file formats, including PostScript®3™, EPS, TIFF, PDF, RGB/CMYK
Environmental considerations
- Temperature: 68-75 °F (20-24 °C)
- Humidity: 50-60%
- Weight: 14,991 lbs. (6,800 kg)
- Printer and dryer dimensions: 319 in x 192 in x 67 in (810 cm x 487 cm x 170 cm)
- Printer electrical: 3 Phase, 480V, 60Hz, 10kW
- Dryer electrical (gas is available as alternative): 3 Phase, 480V, 60Hz, 70kW
- Water pressure: min. 22 psi (1.5 bar); max. 29 psi (2 bar)
- Water volume: 1.3 gallons/ min (5 liters/min)
- Water temperature: 68-77 °F (20-25 °C)
EFI Fiery digital front end
- Ships with an EFI Fiery® proServer Premium, featuring:
- FAST RIP (Fiery Accelerated System Technology)
- FAST DRIVE printer driver
- Spot Color, Color Profiler, Color Verifier, Cut Marks and File Export
- EFI ES-3000 spectrophotometer
- Optimized for one EFI printer
- Drives an additional M–XXL printer option
- Powerful production tools for nesting, step and repeat, scaling, cropping, barcode creation, and tiling
- Advanced ICC color management for proofing-grade reliable color using Fiery Edge™ profiling technology
- Built-in spot color libraries and sophisticated spot color handling
Genuine EFI Inks
Water-based CMYK dispersed dye inks
